1-7Chapter 1: Product introduction
1.5 Motherboard overview
Study the conguration of your chassis to ensure that the motherboard ts before installing
the motherboard.
Ensure that you unplug the power cord before installing or removing the motherboard.
Failure to do so can cause you physical injury and damage motherboard components.
1.5.1 Placement direction
When installing the motherboard, ensure that you place it into the chassis in the correct
orientation. The edge with external ports goes to the rear part of the chassis as indicated in
the image below.
1.5.2 Screw holes
Secure the motherboard to the chassis using six screws as indicated by the circles in the
illustration below.
Do not overtighten the screws! Doing so can damage the motherboard.
Place this side towards
the rear of the chassis
P8H61-M LX R2.0

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H61-I LX R2.0 RM SI and is the answer not in the manual?

Asus P8H61-I LX R2.0 RM SI Specifications

General IconGeneral
Form FactorMini ITX
ChipsetIntel H61
CPU SocketLGA 1155
Memory Slots2 x DIMM
Max Memory16GB
Memory TypeDDR3
Expansion Slots1 x PCIe 2.0 x16
Storage Interfaces4 x SATA 3Gb/s
AudioRealtek ALC887 8-Channel High Definition Audio CODEC
Integrated GraphicsDepends on CPU
LANRealtek 8111E Gigabit LAN
Power Connector24-pin ATX
USB Ports8 x USB 2.0 (4 rear, 4 internal)
