2-16 ASUS P8H61-M LX R2.0
Do not remove the thermal module while changing the DIGI+ VRM related parrameters .
The thermal conditions should be monitored.
Choose a higher value when overclocking, or under a high CPU loading for extra power
support.
iGPU Load-line Calibration [Auto]
Allows you to set the iGPU Load-line Calibration.
Conguration options: [Auto] [Regular] [High] [Extreme]
iGPU Current Capability [100%]
Allows you to set the iGPU Current Capability.
Conguration options: [100%] [110%] [120%] [130%] [140%]
CPU Power Duty Control [T.Probe]
DIGI + VRM Duty control adjusts the current and thermal conditions of every
component’s phase. Conguration options:
[T. Probe] - Select to maintain the VRM thermal balance.
[Extreme] - Select to maintain the current VRM balance.
CPU Current Capability [100%]
Allows you to congure the total power range, and extends the overclocking
frequency range simultaneously.
Conguration options: [100%] [110%] [120%]
DO NOT remove the thermal module when switching to Extreme and Manual Mode. The
thermal conditions should be monitored.
DO NOT remove the thermal module when switching to Manual Mode. The thermal
conditions should be monitored.
CPU Power Phase Control [Standard]
Allows you to control the power phase based on the CPU’s demands.
Conguration options: [Standard] [Optimized] [Extreme] [Manual Adjustment]
CPU Fixed Frequency [xxx]
Frequency switching affects the VRM transient response and the thermal
component. Higher frequency gets quicker transient response. Use the <+> and
<-> keys to adjust the value. The values range from 200k Hz to 350k Hz with a 50k
Hz interval.
