Asus P8H67-M EVO User Manual

ASUS P8H67-M EVO 2-9
Chapter 2
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMM 4 DIMM
Elixir M2F2G64CB88B7N-CG 2GB SS Elixir N2CB2G808N-CG - - • • •
Elixir M2Y2G64CB8HA5N-CG 2GB DS Elixir N2CB1G80AN-C6 - - • •
Elixir M2Y2G64CB8HA9N-CG 2GB DS - - - - • • •
Elixir M2Y2G64CB8HC9N-CG
2GB DS
-
- -
- •
•
•
Elixir M2F4G64CB8HB5N-CG 4GB DS Elixir N2CB2G808N-CG - - • • •
GoodRam GR1333D364L9/2G 2GB DS Qimonda IDSH1G-03A1F1C-13H - - • • •
KINGTIGER F10DA2T1680 2GB DS KINGTIGER KTG1333PS1208NST-C9 - - • • •
KINGTIGER KTG2G1333PG3 2GB DS - - - - • • •
Patriot PDC32G1333LLK 1GB SS PATRIOT - 7 1.7 • • •
Patriot
PVT33G1333ELK
3GB
(3 x 1GB)
SS
-
- 9-9-9-24
1.65 •
•
•
Patriot PGS34G1333LLKA
4GB
(2 x 2GB)
DS - - 7-7-7-20 1.7 • • •
Patriot PVS34G1333ELK
4GB
(2 x 2GB)
DS - - 9-9-9-24 1.5 •
Patriot PVS34G1333LLK
4GB
(2 x 2GB)
DS - - 7-7-7-20 1.7 • •
Patriot PVT36G1333ELK
6GB
(3 x 2GB)
DS - - 9-9-9-24 1.65 • • •
Silicon
Power
SP001GBLTU1333S01 1GB SS NANYA NT5CB128M8AN-CG - - • • •
Silicon
Power
SP001GBLTU133S02 1GB SS S-POWER I0YT3E0 9 - • • •
Silicon
Power
SP002GBLTU133S02 2GB DS S-POWER I0YT3E0 9 - • • •
Slicon
Power
SP001GBLTE133S01 1GB SS NANYA NT5CB128M8AN-CG - - • • •
Slicon
Power
SP002GBLTE133S01 2GB DS NANYA NT5CB128M8AN-CG - - • • •
UMAX E41302GP0-73BDB 2GB DS UMAX U2S24D30TP-13 - • •
P8H67-M EVO Motherboard Qualied Vendors Lists (QVL) DDR3-1333MHz capability
(continued)
Vendors Part No. Size
SS/
DS
Chip Brand Chip NO. Timing Voltage
DIMM socket support
(Optional)
1 DIMM 2 DIMM 4 DIMM
Crucial CT12864BA1067.8FF 1GB SS MICRON D9KPT 7 - • • •
Crucial CT12864BA1067.8SFD 1GB SS MICRON D9JNL 7 - • • •
Crucial CT12872BA1067.9FF 1GB SS MICRON D9KPT(ECC) 7 - • • •
Crucial CT25664BA1067.16FF 2GB DS MICRON D9KPT 7 - • • •
Crucial CT25664BA1067.16SFD 2GB DS MICRON D9JNL 7 - • • •
Crucial CT25672BA1067.18FF 2GB DS MICRON D9KPT(ECC) 7 - • • •
ELPIDA EBJ10UE8BAW0-AE-E 1GB SS ELPIDA J1108BABG-DJ-E 7 - • • •
ELPIDA EBJ10UE8EDF0-AE-F 1GB SS ELPIDA J1108EDSE-DJ-F - - • • •
ELPIDA EBJ11UD8BAFA-AG-E 1GB DS ELPIDA J5308BASE-AC-E 8 - • •
ELPIDA EBJ21UE8BAW0-AE-E 2GB DS ELPIDA J1108BABG-DJ-E 7 - • • •
ELPIDA EBJ21UE8EDF0-AE-F 2GB DS ELPIDA J1108EDSE-DJ-F - - • • •
GEIL GG34GB1066C8DC
4GB
(2 x 2GB)
DS GEIL GL1L128M88BA115FW 8-8-8-20 1.3 • • •
Hynix HMT112U6AFP8C-G7N0 1GB SS HYNIX H5TQ1G83AFPG7C 7 - • • •
Hynix HYMT112U64ZNF8-G7 1GB SS HYNIX HY5TQ1G831ZNFP-G7 7 - • •
Hynix HMT125U6AFP8C-G7N0 2GB DS HYNIX H5TQ1G83AFPG7C 7 - • • •
Hynix HYMT125U64ZNF8-G7 2GB DS HYNIX HY5TQ1G831ZNFP-G7 7 - • • •
Kingston KVR1066D3N7/1G 1GB SS Kingston D1288JPNDPLD9U 7 1.5 • • •
Kingston KVR1066D3N7/2G 2GB DS Elpida J1108BDSE-DJ-F 7 1.5 • • •
MICRON MT8JTF12864AZ-1G1F1 1GB SS MICRON 8ZF22 D9KPV 7 - • • •
MICRON MT8JTF12864AZ-1G1F1 1GB SS MICRON D9KPT 7 - • • •
MICRON MT9JSF12872AZ-1G1F1 1GB SS MICRON D9KPT(ECC) 7 - • • •
MICRON MT16JTF25664AZ-1G1F1 2GB DS MICRON 8ZF22 D9KPV 7 - • • •
P8H67-M EVO Motherboard Qualied Vendors Lists (QVL) DDR3-1066MHz capability

Asus P8H67-M EVO Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
CPU Socket	LGA 1155
Maximum Memory	32GB
Memory Type	DDR3
PCI Express 2.0 x1	2
PCI Slots	1
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports	2
USB 2.0 Ports	12
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E Gigabit LAN controller
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
Memory Standard	DDR3 1333/1066 MHz
Onboard Video	Supported only by CPU with integrated graphics
