Asus P8H67-M EVO User Manual

ASUS P8H67-M EVO 2-3
Chapter 2
2.2.2 Layout contents
Connectors/Jumpers/Slots Page
1. CPU, chassis, and power fan connectors (4-pin CPU_FAN,
4-pin CHA_FAN1, 3-pin PWR_FAN)
2-24
2. LGA1155 CPU Socket 2-4
3. ATX power connectors (24-pin EATXPWR, 8-pin EATX12V) 2-25
4. DDR3 DIMM slots 2-5
5. MemOK! switch 2-13
6. IDE connector (40-1 pin PRI_EIDE) 2-20
7. Serial port connector (10-1 pin COM1) 2-22
8. Intel
®
H67 Serial ATA 6.0 Gb/s connectors
(7-pin SATA6G_1/2 [gray])
2-18
9. Intel
®
H67 Serial ATA 3.0 Gb/s connectors
(7-pin SATA3G_3–6 [blue])
2-19
10. TPM connector (20-1 pin TPM) 2-24
11. System panel connector (20-8 pin PANEL) 2-26
12. Clear RTC RAM (3-pin CLRTC) 2-17
13. EPU switch 2-14
14. USB 2.0 connectors (10-1 pin USB78, USB910, USB1112,
USB1314)
2-21
15. GPU Boost switch 2-14
16. IEEE 1394a connector (10-1 pin IE1394_2) 2-22
17. Digital audio connector (4-1 pin SPDIF_OUT) 2-23
18. Front panel audio connector (10-1 pin AAFP) 2-23
19. Standby power LED 2-15

Asus P8H67-M EVO Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
CPU Socket	LGA 1155
Maximum Memory	32GB
Memory Type	DDR3
PCI Express 2.0 x1	2
PCI Slots	1
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports	2
USB 2.0 Ports	12
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E Gigabit LAN controller
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
Memory Standard	DDR3 1333/1066 MHz
Onboard Video	Supported only by CPU with integrated graphics
