3-36 Chapter 3: BIOS setup
Chapter 3
Booting the system in DOS environment
1. Insert the USB ash drive with the latest BIOS le and BIOS Updater to the USB port.
2. Boot your computer. When the ASUS Logo appears, press <F8> to show the BIOS
Boot Device Select Menu. Insert the support DVD into the optical drive and select the
optical drive as the boot device.
Welcome to FreeDOS (http://www.freedos.org)!
C:\>d:
D:\>
3. When the Make Disk menu appears, select the FreeDOS command prompt item by
pressing the item number.
4. At the FreeDOS prompt, type d: and press <Enter> to switch the disk from
Drive C (optical drive) to Drive D (USB ash drive).
3.10.4 ASUS BIOS Updater
The ASUS BIOS Updater allows you to update BIOS in DOS environment. This utility also
allows you to copy the current BIOS le that you can use as a backup when the BIOS fails or
gets corrupted during the updating process.
The succeeding utility screens are for reference only. The actual utility screen displays may
not be same as shown.
Before updating BIOS
1. Prepare the motherboard support DVD and a USB ash drive in FAT32/16 format and
single partition.
2. Download the latest BIOS le and BIOS Updater from the ASUS website at http://
support.asus.com and save them on the USB ash drive.
NTFS is not supported under DOS environment. Do not save the BIOS le and BIOS
Updater to a hard disk drive or USB ash drive in NTFS format.
Do not save the BIOS le to a oppy disk due to low disk capacity.
3. Turn off the computer and disconnect all SATA hard disk drives (optional).
Please select boot device:
SATA: XXXXXXXXXXXXXXXX
USB XXXXXXXXXXXXXXXXX
UEFI: XXXXXXXXXXXXXXXX
Enter Setup
and to move selection
ENTER to select boot device
ESC to boot using defaults

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Asus P8H67-M EVO and is the answer not in the manual?

Asus P8H67-M EVO Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel H67
CPU SocketLGA 1155
Maximum Memory32GB
Memory TypeDDR3
PCI Express 2.0 x12
PCI Slots1
SATA 6Gb/s2
SATA 3Gb/s4
USB 3.0 Ports2
USB 2.0 Ports12
AudioRealtek ALC892 8-Channel High Definition Audio CODEC
LANRealtek 8111E Gigabit LAN controller
RAID SupportRAID 0, 1, 5, 10
Memory Slots4 x DIMM
Memory StandardDDR3 1333/1066 MHz
Onboard VideoSupported only by CPU with integrated graphics
