Asus P8H67-M EVO User Manual

ASUS P8H67-M EVO 3-11
Chapter 3
Black Yellow Pink Red
CPU Voltage
+/- 0.005V–
+/- 0.110V
+/- 0.115V +/-0.120V
+/- 0.125V–
+/- 0.635V
iGPU Voltage
+/- 0.005V–
+/- 0.110V
+/- 0.115V +/-0.120V
+/- 0.125V–
+/- 0.635V
DRAM Voltage
1.20V–
1.57V
1.58V–
1.65V
1.66V–
1.72V
1.73V–
2.20V
VCCIO Voltage
0.80V–
1.10V
1.11V–
1.15V
1.16V–
1.20V
1.21V–
1.70V
CPU PLL Voltage
1.20V–
1.89V
1.90V–
1.98V
1.99V–
2.07V
2.08V–
2.20V
PCH Voltage
0.80V–
1.10V
1.11V–
1.15V
1.16V–
1.20V
1.21V–
1.45V
Load-Line Calibration [Auto]
Allows you to set the CPU Load-Line percentage.
Conguration options: [Auto] [Disabled] [Enabled][Auto] [Disabled] [Enabled]
CPU Spread Spectrum [Auto]
[Auto] Automatic conguration.
[Disabled] Enhances the BCLK overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.

Asus P8H67-M EVO Specifications

General

Form Factor	Micro ATX
Chipset	Intel H67
CPU Socket	LGA 1155
Maximum Memory	32GB
Memory Type	DDR3
PCI Express 2.0 x1	2
PCI Slots	1
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 3.0 Ports	2
USB 2.0 Ports	12
Audio	Realtek ALC892 8-Channel High Definition Audio CODEC
LAN	Realtek 8111E Gigabit LAN controller
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4 x DIMM
Memory Standard	DDR3 1333/1066 MHz
Onboard Video	Supported only by CPU with integrated graphics
