6-4 Chapter 6: Driver installation
8. Select YES from the following warning message then press <Enter>.
WARNING !!!
NO
YES
)DO YOU WANT TO CONTINUE ?
ALL DATA ON THE FLOPPY DISKETTE WILL BE DELETED !!
9. On the following Important message, select YES if an ASMB7 is installed, otherwise
select NO, then press <Enter>.
NO
YES
YES
<Important>
Please ensure ASMB7-iKVM is well installed on the
motherboard.
10. Insert the formatted diskette into the disk drive and press <Enter> to write the image to
the disk.
11. Press any key to continue when prompted.
The Create Driver Diskette Menu appears after the creation of the diskette is finished.
To create a RAID driver disk in Windows
®
environment:
1. Start Windows
®
.
2. Place the motherboard support DVD into the optical drive.
3. Go to the Make disk
menu, then select the type of RAID driver disk you want to create.
4. Insert a floppy disk into the USB floppy disk drive.
5. Follow succeeding screen instructions to complete the process.
Write-protect the floppy disk to avoid computer virus infection.

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
