Asus P9D-E/4L User Manual

1-4
Chapter 1: Product introduction
1.4 Special features
1.4.1 Product highlights
Latest processor technology
This motherboard supports the latest Intel
®
Xeon
®
Processor E3-1200 v3/
Core
TM
i3 series in LGA1150 package, which has memory and PCI Express
controller integrated to support 2-channel (4 DIMMs) DDR3 memory and 16 PCI
Express 3.0 lanes. The Intel
®
Xeon
®
E3-1200 v3 have improve CPU performance
and integrated voltage regulators making it one of the most powerful and energy
efficient CPU in the world.
Intel
®
Turbo Boost
Intel
®
Turbo Boost automatically allows the processor to run faster than the marked
frequency if the processor is operating below its power, current, and temperature
specification limits. This technology increases performance of both multi-threaded
and single-threaded workloads.
Intel
®
Hyper Threading
The thread-level parallelism on each processor makes more efficient use of the
processor resources, higher processing throughout and improved performance on
today's multi-threaded software.
Intel
®
EM64T
The motherboard supports Intel
®
processors with the Intel
®
EM64T (Extended
Memory 64 Technology). The Intel
®
EM64T feature allows your computer to run on
64-bit operating systems and access larger amounts of system memory for faster
and more efficient computing.
DDR3 memory support
The motherboard supports ECC UDIMM DDR3 memory that features data
transfer rates of 1600/1333 MHz to meet the higher bandwidth requirements of
server and workstation applications. The dual-channel DDR3 architecture boosts
system performance, eliminates bottlenecks with peak bandwidth up to 25Gb/s,
and dramatically reduces the memory voltage to just 1.5V compared to DDR2's
memory voltage of 1.8V.
1.3 Serial number label
Before requesting support from the ASUS Technical Support team, you must take
note of the motherboard's serial number containing 12 characters
xxS2xxxxxxxx
shown as the figure below. With the correct serial number of the product, ASUS
Technical Support team members can then offer a quicker and satisfying solution
to your problems.
xxS2xxxxxxxx
P9D-E/4L
Made
in
China
合格

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
