2.5.11 Connecting the Thermal sensor cable
Follow the steps below to connect the Thermal sensor (TR1) cable to the connector on your
motherboard.
1. Locate the Thermal Sensor (TR1)
connector on the motherboard.
2. Connect the Thermal Sensor cable to
the connector.
3. Place the other end of the Thermal Sensor cable to the device you would like to monitor
temperature.
The motherboard illustration is for reference only. The motherboard layout and appearance
may vary depending on the model, but the installation steps remain the same.
