Asus P9D-E/4L User Manual

2-6
Chapter 2: Hardware information
2.2.4 Layout contents
Jumpers Page
1. Clear RTC RAM (CLRTC1)
2-25
2. VGA controller setting (3-pin VGA_SW1)
2-26
3.
LAN controller setting
(3-pin LAN_SW1, LAN_SW2, LAN_SW3, LAN_SW4)
2-26
4. RAID configuration utility selection (3-pin RAID_SEL1)
2-27
5. Platform Environmental Control Interface (PECI) Setting
(3-pin PECI1)
2-27
Rear panel connectors Page
1. PS/2 keyboard/mouse port (purple/green) 2-28
2.
RJ-45 port for iKVM 2-28
3.
Video Graphics Adapter port 2-28
4.
RJ-45 ports for LAN. 2-28
5.
Power-on Button 2-28
6.
Location LED
2-28
7.
Power LED
2-28
8.
USB 2.0 ports 1 and 2 2-28
9. USB 3.0 ports 1 and 2
2-28
Slots/Sockets Page
1. CPU sockets 2-8
2. DDR3 sockets
2-14
3. PCI Express x16 / PCI Express x8 / PCI Express x1 / PCI slot
2-17
4. PIKE slot
2-18
Onboard LEDs
Page
1. Standby Power LED (SB_PWR1)
2-22
2.
Baseboard Management Controller LED (BMC_LED1)
2-22
3.
CPU Warning LED (ERR_CPU1)
2-23
4.
Power LED (+5V_LED) 2-23
5.
Location LED (LOCLED1) 2-24

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
