Page #97 background imageLoading...
Page #97 background image
4-32
Chapter 4: BIOS setup
4.6 Boot menu
The items in Boot menu allows you to change the options on how the system will
boot.
Setup Prompt Timeout [xx]
This item allows you to adjust the number of seconds to wait for setup activation
key. Use the <+> and <-> keys to specify the values.
Bootup NumLock State [On]
Allows you to select the power-on state for the NumLock. Configuration options:
[Off] [On]
Full Screen Logo [Enabled]
Allows you to enable or disable the full screen logo display feature. Configuration
options: [Disabled] [Enabled]
.
Set the
Full Screen Logo
to [Enabled] to use the ASUS MyLogo2™ feature.
GateA20 Active [Upon Request]
This item is useful when any RT code is execute above 1MB. When set to [Upon
Request], the GA20 can be disabled using BIOS services. When set to [Always],
disabling of GA20 is not allowed. Configuration options: [Upon Request] [Always]
.
Option ROM Messages [Force BIOS]
Allows you to set the display mode for Option ROM. Configuration options:
[Force BIOS] [Keep Current]
Number of seconds to wait
for setup activation key.
65535(0xFFFF) means
indenite waiting.
Boot Conguration
Setup Prompt Timeout 1
Bootup NumLock State [On]
Full Screen Logo [Enabled]
CSM16 Module Version 07.69
GateA20 Active [Upon Request]
Option ROM Messages [Force BIOS]
INT19 Trap Response [Immediate]
Boot Device Seeking [Endless PXE]
Boot Option Priorities
Boot Option #1 [P0: DVD ]
Boot Option #2 [P4: Harddisk 2.50G]
Boot Option #3 [Windows Boot Man..]
Network Device BBS Priorities
Hard Drive BBS Priorities
CSM parameters
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Main Advanced Event Logs Boot Monitor Security Tool Exit
Boot
