4-20
Chapter 4: BIOS setup
PCIE Slot Conguration
Allows you to perform PCIE slot configurations.
PCIE Option Rom 3 - 7 [Enabled]
Allows you to enable or disable the PCIE slots. Configuration Options:
[Disabled][Enabled]
PIKE Option Rom
[Enabled]
Allows you to enable or disable the PIKE Option Rom. Configuration Options:
[Disabled][Enabled]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Advanced
PCIE Slot Conguration
PCIE3 Not Present
PCIE3 Option Rom [Enabled]
PCIE4 Not Present
PCIE4 Option Rom [Enabled]
PCIE5 Not Present
PCIE5 Option Rom [Enabled]
PCIE6 Not Present
PCIE6 Option Rom [Enabled]
PCIE7 Not Present
PCIE7 Option Rom [Enabled]
PIKE Not Present
PIKE Option Rom [Enabled]
Enabled/Disabled PCIE3
Option Rom
