4-28
Chapter 4: BIOS setup
Serial Port for Out-of-Band Management/Windows Emergency Management
Services (EMS) Settings
The following items only appears when you set the
Console Redirection
to [Enabled].
Out-of-Band Mgmt Port [COM1]
Allows remote management of a Windows Server OS through a serial port. Configuration
options: [COM1] [COM2]
Terminal Type [VT-UTF8]
Allows you to set the terminal type for out-of-band management. Configuration options:
[VT100] ASCII char set.
[VT100+] Extends VT100 to support color, function keys, et.
[VT-UTF8] Uses UTF8 encoding to map Unicode chars onto 1 or more bytes
[ANSI] Extended ASCII char set
Bits per second [115200]
Selects serial port transmission speed. The speed must be matched on the other side. Long
or noisy lines may require lower speeds. Configuration options: [9600] [19200] [38400]
[57600] [115200]
Flow Control [None]
Allows you to set the flow control to prevent data loss from buffer overflow. Configuration
options: [None] [Hardware RTS/CTS] [Software Xon/Xoff]
