Asus P9D-E/4L User Manual

4-34
Chapter 4: BIOS setup
This option controls if
CSM will be launched.
Launch CSM [Enabled]
Boot Option lter [Legacy only]
Launch PXE OpROM policy [Legacy only]
Launch Storage OpRom policy [Legacy only]
Launch Video OpRom policy [Legacy only]
Other PCI device ROM priority [Legacy OpROM]
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Boot
CSM Parameters
This allows you to set OpROM execution, boot options filter, and other OpROM
settings settings.
Launch CSM [Enabled]
This option allows you to enable or disable the launch of CSM. Configuration options:
[Disabled] [Enabled]
Boot Option filter [Legacy only]
This option allows you to control what devices the system can boot to. Configuration options:
[UEFI and Legacy] [Legacy only] [UEFI only]
Launch PXE OpROM policy [Legacy only]
This option allows you to control the execution of UEFI and Legacy PXE OpROM.
Configuration options: [Do not launch] [UEFI only] [Legacy only] [Legacy first] [UEFI first]
Launch Storage OpROM policy [Legacy only]
This option allows you to control the execution of UEFI and Legacy Storage OpROM.
Configuration options: [Do not launch] [UEFI only] [Legacy only] [Legacy first] [UEFI first]
Launch Video OpROM policy [Legacy only]
This option allows you to control the execution of UEFI and Legacy Storage OpROM.
Configuration options: [Do not launch] [UEFI only] [Legacy only] [Legacy first] [UEFI first]
Other PCI device ROM priority [Legacy OpROM]
This option allows you to control the execution of UEFI and Legacy Storage OpROM.
Configuration options: [UEFI OpROM] [Legacy OpROM]

Asus P9D-E/4L Specifications

General

USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1, 2
Maximum UDIMM memory	32 GB
Supported DIMM module capacities	2GB, 4GB, 8GB
TPM connector	Yes
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1333, 1600 MHz
PCI Express x8 (Gen 2.x) slots	0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA II, SATA III
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
On-board graphics card model	Aspeed AST2300
On-board graphics card memory	32 MB
Cables included	SATA, USB-SATA
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	20 - 90 %
Processor socket	LGA 1150 (Socket H3)
Intel Xeon series	E3-1200
Processor manufacturer	Intel
Motherboard chipset	Intel® C224
Motherboard form factor	ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	243.84 mm
Width	304.8 mm
