Asus ROG SWIFT PG32UQXR User Manual

3-6
Chapter 3: OSD (On-Screen Display) menu
5. PIP/PBP Setup
The PIP/PBP Setup allows you to open up sub-window(s) connected from
any video source.
To activate this function, you need to do the following: turn off Dynamic
Dimming, turn off VRR and disable HDR on your device.
Back Enter Select Exit
Volume 80
Input Select
DisplayPort-1
PIP/PBP Mode
PIP/PBP Source
Color Setting
PIP Size
GameVisual
Racing Mode
HDR
OFF
160Hz
3840x2160
Gaming
Color
Input Select
PIP/PBP Setup
• PIP/PBP Mode: Selects PIP, PBP mode or turn it off.
• PIP/PBP Source: Selects the video input source from among HDMI-1,
HDMI-2, DisplayPort-1, and DisplayPort-2.
• Color Setting: Sets GameVisual mode for each PIP/PBP window.
• PIP Size: Adjusts the PIP size to Small, Middle, or Large.
6. Lighting Effect
Back Enter Select Exit
Volume 80
Input Select
DisplayPort-1
Aura Sync
Aura RGB
GameVisual
Racing Mode
HDR
OFF
160Hz
3840x2160
Lighting Effect
MyFavorite
System Setup
• Aura Sync: Allows you to turn on or off the Aura Sync function that
synchronizes the Aura RGB light effect among all supported devices.
• Aura RGB: There are 5 living colors can be chosen: Color Cycle, Static,
Breathing, Strobing, OFF. You can manually change the R/G/B/C/M/Y
color for Static, Breathing, and Strobing modes.

Asus ROG SWIFT PG32UQXR Specifications

General

Color gamut	96 %
Pixel pitch	0.1845 x 0.1845 mm
Screen shape	Flat
Display surface	Matt
Display diagonal	32 \
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	160 Hz
Viewable size, vertical	398.52 mm
sRGB coverage (typical)	160 %
Contrast ratio (typical)	1000:1
Display number of colors	1.073 billion colors
Display brightness (peak)	1000 cd/m²
Viewable size, horizontal	708.48 mm
Digital vertical frequency	24 - 160 Hz
Digital horizontal frequency	352 - 352 kHz
Display brightness (typical)	400 cd/m²
High Dynamic Range (HDR) supported	Yes
High Dynamic Range (HDR) technology	High Dynamic Range 10 (HDR10)
AMD FreeSync type	FreeSync Premium Pro
HDCP version	2.2
Headphone outputs	1
DisplayPort version	2.1
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	3
Product color	Black
Market positioning	Gaming
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.3 W
Power consumption (standby)	- W
Power consumption (typical)	51 W
Power consumption (PowerSave)	0.5 W
Tilt angle range	20 - -5 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
Package type	Box
Package depth	640 mm
Package width	829 mm
Package height	282 mm
Package weight	15900 g

Weight and Dimensions

Depth (with stand)	279 mm
Width (with stand)	726 mm
Height (with stand)	541 mm
Weight (with stand)	10800 g
Depth (without stand)	95 mm
Height (without stand)	441 mm
Weight (without stand)	7200 g
