Chapter 1: Product introduction1-6
1.6 Internal features
The barebone server includes the basic components as shown.
1. Power supply and power
fan
2. PCI Express slot Riser Card
3. ASUS P8B-E/4L server
boards
4. System fans
5. SAS / SATA backplane
(hidden)
6. HDD tray 1—Connect to
SATA1 port (SATA 6Gb/s)
7. HDD tray 2—Connect to
SATA2 port (SATA 6Gb/s)
8. HDD tray 3—Connect to
SATA3 port
9. HDD tray 4—Connect to
SATA4 port
10. Front I/O boards (hidden)
11. Slim-type optical drive
The barebone server does not include a oppy disk drive drive. Connect a USB
oppy disk drive to any of the USB ports on the front or rear panel if you need to
use a oppy disk.
*WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
Turn off the system power and detach the power supply before removing or
replacing any system component.
5
1
2
3
4 4 4 4
10
96 7
8
11
