Chapter 2: Hardware setup2-18
2.8.2 Installing ASUS PIKE RAID card (optional)
Follow the steps below to install an optional ASUS RAID card on your motherboard.
1. Locate the PIKE RAID card slot on
the motherboard.
2. Align the golden ngers of the
RAID card with the PIKE RAID card
slot.
3. Insert the RAID card into the PIKE
RAID card slot. Ensure that it is
completely seated on the PIKE
RAID card slot.
4. Remove the SATA/SAS cables from
the onboard SATA1–4 connectors.
