Asus RS300-E7/PS4 - Installing Optional Ball-Bearing Rail Kit Items; Attaching the Rails to the Server

3-5ASUS RS300-E7/PS4
3.2 Installing optional ball-bearing rail kit
items
Your optional ball-bearing rail kit package contains:
• two pair of server rails (for the server)
• two pairs of rack rails (for the rack)
• Nut-and-bolt type screws
3.2.1 Attaching the rails to the server
To attach the server rails:
1. Attach the front end of the server
rail to the side of the chassis,
matching each of the three hooks
to the holes on the rail. Then slide
the rail toward the front panel until it
locks in place.
Rack railsFront endRear endNuts and screws
2. Secure the front end of the server
rail to the side of the chassis with
one screw.
