ASUS RS300-E7/PS4 5-21
INTEL W82574L OpROM1/OpROM2 [PXE]
INTEL W82574L OpROM3/OpROM4 [Disabled]
Allows you to select the options for the OptionRom of the Intel LAN controllers.
Conguration options: [Disabled] [PXE] [iSCSI]
SerialPort1/2Conguration
The sub-items in this menu allow you to set the serial port 1/2 conguration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Conguration options: [Enabled] [Disabled]
Change Settings [Auto]
Allows you to select the serial port base address.
Conguration options: [Auto] [IO=3F8h; IRQ=4]
[IO=3F8h: IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
ParallelPortConguration
The sub-items in this menu allow you to set the parallel port conguration.
Parallel Port [Enabled]
Allows you to enable or disable the parallel port (LPT/LPTE).
Conguration options: [Enabled] [Disabled]
Change Settings [Auto]
Allows you to select an optimal setting for the super IO device.
Conguration options: [Auto] [IO=378h; IRQ=5]
[IO=378h: IRQ=5, 6, 7, 9, 10, 11, 12] [IO=278h; IRQ=5, 6, 7, 9, 10, 11, 12]
[IO=3BCh; IRQ=5, 6, 7, 9, 10, 11, 12]
Device Mode [STD Printer Mode]
Allows you to select the printer port mode.
Conguration options: [STD Printer mode] [SPP Mode] [EPP-1.9 and SPP
Mode] [EPP-1.7 and SPP Mode] [ECP Mode] [ECP and EPP 1.9 Mode] [ECP
and EPP 1.7 Mode]
