ASUS STRIX Sound Card Series User Manual
English
2. Hardware overview
No. Items Description
1
Microphone In port
Connect your external PC microphone to this 3.5mm
port for voice input. Built-in high-quality Microphone
pre-amplier.
Line In port
Connect analog devices like MP3 players, CD players,
music synthesizers, and other line-level sound sources
to this 3.5mm port for audio recording or processing.
2. Headphone Out port Connect your headphone to this port.
Side+
S/PDIF Out
Mic/Line-in
Headphone
Front
Box Link
Rear
Center
1
2
3
4
5
6
7
