ASUS TW300-E5/PI4 5-15
5.3.4 Creating a RAID 5 set (Parity)
To create a RAID 5 set:
1. From the utility main menu, select 1. Create RAID Volume, then press
<Enter>. This screen appears.
2. Enter a name for the RAID 10 set, then press <Enter>.
3. Highlight RAID Level, press the up/down arrow key to select
RAID 5, then press <Enter>.
4. Follow steps 4 to 9 of section 5.3.1 Creating a RAID 0 set (striped) to create
the RAID 5 set.
Intel(R) Matrix Storage Manager Option ROM v5.6.2.1002 ICH9R wRAID5
Copyright(C) 2003-05 Intel Corporation. All Rights Reserved.
[ CREATE ARRAY MENU ]
[ DISK/VOLUME INFORMATION ]
Enter a string between 1 and 16 characters in length that can be used
to uniquely identify the RAID volume. This name is case sensitive and cannot
contain special characters.
Name:
RAID Level:
Disks:
Strip Size:
Capacity:
Volume1
RAID5(Parity)
Select Disks
128KB
0.0 GB
Create Volume
[
↑↓
]-Select [ESC]-Exit [ENTER]-Select Menu
