Asus TW300-E5/PI4 User Manual

2-3ASUS TW300-E5/PI4
2.1.2 Removing the right side cover
Most internal components can be installed or replaced after removing the left
side cover. However, for components such as Serial ATA hard disk drives, you
may have to remove the right side cover for easier component installation or
replacement.
To remove the right side cover
1. Remove the two screws that secure
the left side cover to the chassis.
2
2. Slide the right side cover for about
half an inch toward the rear until it
is disengaged from the chassis.
3. Carefully lift the cover and set it
aside.
1
1
