ASUS Xonar U7 User Manual
English
Connecting 4 channel speakers / power amplier
No. Items Description
1. Front (R) Out port Connects to the front right input port of 4 channel
speakers.
2. Front (L) Out port Connects to the front left input port of 4 channel
speakers.
3. Rear Surround Out
port
Connects to the rear surround input port of 4 channel
speakers.
Amplifier
