Asus Xonar U7 - 4.2.5 Connecting 5.1 channel speakers

17
ASUS Xonar U7 User Manual
English
Connecting 5.1 channel speakers
No. Items Description
1. Front (R) Out port Connects to the front right input port of 5.1 channel
speakers.
2. Front (L) Out port Connects to the front left input port of 5.1 channel
speakers.
3. Center/Subwoofer
Out port
Connects to the Center and Subwoofer input ports of 5.1
channel speakers.
4. Rear Surround Out
port
Connects to the rear surround input port of 5.1 channel
speakers.
