20. Specifications
Technical Specifications GDO-6V4
EasyRoller
®
GDO-6V3
EasyRoller
®
Power supply 230V - 240Va.c. 50Hz 230V - 240Va.c. 50Hz
Maximum door opening
Door Height:
Maximum Door Weight:
Door Area:
Door must be well balanced and
able to be operated by hand, as per
warranty conditions and standard
AS/NZS 4505:2012
3.25 turns of the drum wheel
(approx. 3000mm)
110kg
16.5m
2
3.25 turns of the drum wheel
(approx. 3000mm)
110kg
16.5m
2
Minimum sideroom 40mm 40mm
Lift Force 600N 600N
Nominal force 150N (15kg) 150N (15kg)
Receiver type Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Multi-frequency UHF FM
(433.47, 433.92 & 434.37MHz)
Receiver code storage capacity 64 X Triocode
TM
128
4-button Transmitters
14 X Triocode
TM
128
4-button Transmitters
Coding System TrioCode
TM
128 Type TrioCode
TM
128 Type
Coding type Non-linear encryption algorithm Non-linear encryption algorithm
Number of code combinations Over 100 billion random codes Over 100 billion random codes
Transmitter battery CR2032 (3 Volts) CR2032 (3 Volts)
Courtesy light LED (Light Emitting Diodes) Festoon style lamp 24volts 15 watts
Network connectivity Network compatible,
(requires optional
Smart Phone Control Kit)
Not Available
Note: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra pressure on the
door and tracks which may in turn intermittently trigger the safety obstruction detection system.
