GB 22
What you need to consider
Safety instructions for the installation
• The connection must comply with national and local regulations.
• The appliance must always be earthed.
• This appliance may only be connected by a competent electrical
installer.
• For the connection, use an approved cable (for example type
HO5RR) in accordance with the regulations. The cable casing
should be of rubber.
• The connection cable must hang freely and is not to be fed through
a drawer.
• If you want to make a fixed connection, make sure that a multi-
polar switch with a contact separation of at least 3 mm is fitted in
the supply line.
• The worktop the hob is built into must be flat.
• The walls and the worktop surrounding the appliance must be heat
resistant up to at least 85 °C. Even though the appliance itself does
not get hot, the heat of the hot pan could discolour or deform the
wall.
• Damage caused by incorrect connection, installation or use, will not
be covered by the guarantee.
Clearance
Sufficient all-round clearance is essential to the safe use of the hob.
Check that there is enough clearance.
cooker hood
cabinet
side wall
hob
HL6271T: 600 mm
HL6271G: 600 mm
HL6271M: 640 mm
HL7271G: 770 mm
HL7271M: 770 mm
INSTALLATION
*
