GB 25
INSTALLATION
If the hob is wider than the cupboard, with a worktop less than 43 mm
thick, saw a cut-out in both sides of the cupboard, so the appliance is
detached from the cupboard.
Y
Y
X
600
Installation dimensions
inside the cabinet
x<43 mm: y = 43 mm - x
x>= 43 mm: y = 0 mm
