Installation instructions E-SHR series page 28
16.2 radiator installation with thermostat valves only
connecting of the boiler to a radiator installation with thermostat valves only figure 19
1
2
3
4
5
6
1 ATAG Premier boiler
2 expansion vessel
3 outside sensor ARV12
4 drain points
5 ATAG room thermostat
6 by-pass
trv thermostatic radiator valve
trv trv
