Atag XL-W Series User Manual

55
Standard Schemes
ATAG XL-W + 1 Mixing circuit +1 Direct circuit + Low loss header
Hydraulic Schematic
AAV Automac air vent
ADS Air dirt separator
BV Balancing valve
C.Pi Condensing pipe
CWS Cold water supply
DP Dosing pot
DV Drain valve
EV Expansion vessel
GSV Gas shut o valve
HC Heang Circuit
IV Isolaon valve
LLH Low loss header
MF Dirt separator magnec lter
NRV Non return valve
OF Overow pipe
PU Pressurizaon unit
RT1/RT2 Room thermostat (on/o)
S Strainer
T Flow sensor
T10 Common sensor ow
T7 Outdoor sensor
WM Water meter
Gas
Return
Flow
Sensor
BUS connecon cable
Pump cable
Oponal components
Mixing valve cable
