ATAGO VISCO-895 User Manual

Quick Manual (using L Beaker as an example)
1. Setup (
C
p.9)
① Rotate the main unit's legs and
position it upright.
② Place the main unit on the stand.
2. Power ON (
C
p.10)
① Push the dial button (for at least 0.5
seconds).
The main menu screen will be
displayed.
3. Level Check (
C
p.12)
① Use the screws at the base of the
stand to adjust the level. Align the
mark with the center of the screen.
4. Spindle and Beaker Selection
(
C
from p.42)
① Refer to the "Maximum
Measurement Values Guideline
Chart" and select the most suitable
spindle and beaker for your
application.
5. Spindle and Temperature
Sensor Preparation
(
C
from p.14)
① Attach the spindle and the
temperature sensor to the main unit.
20.0° C
Measurement
Level
Auto Stop
User Scale
Setup
Beaker Spindle
20.0° C
Center
Mark
Shaft holder
Temperature sensor
attachment point
Main unit
Stand
