Battery installation
continued from page 11
3. Pull on the tab to remove the battery compartment cover.
4. Insert a 9V battery (purchased separately) following the
polarity markings in the battery compartment.
5. Replace the battery compartment cover and the screw.
6. If you are wall mounting the phone, turn to Wall installation
beginning on page 15. (You will not need the wedge; store it in case
you use the phone on a table or desk in the future.)
—OR—
If you are using the phone on a table or desk, reattach the
wedge to the base unit by sliding the tabs into the holes as shown.
Snap the wedge onto the base. Then, turn to Table/desk installation
beginning on page 13.
12
Installation
Installation
Polarity
markings
