AT&T TL7601 User Manual

Remote dial pad operation
Screen icons & display screen messages
15
Screen icons
The remote dial pad works with headset 1.
The remote dial pad works with headset 2.
The telephone line is in use.
Battery charging (animated display).
1
2
Display screen messages
The remote dial pad is in idle
mode.
DIAL PAD
ENDED
CONNECTING ...
You have just ended a call.
The remote dial pad is
registering to the headset base,
or has lost communication with
the headset base.
CHARGING
The remote dial pad with a low
battery has been placed in the
remote dial pad charger.
DIAL PAD
REGISTERED
The dial pad has been
successfully registered to the
headset base.
PHONE 0:00:30
1-234-5678
1
