SECTION 5
1200XL PARTS LIST
MAJOR ASSEMBLIES
LINE NO. DESCRIPTION PART NO.
1. Final Assembly (unpackaged) CA060276
2. Top Cover Assembly CA060278
3. PCB-RFI Shield Assembly CA061074
4. Bottom Cover Assembly CA060277
5. Cartridge Conn Panel C060096
Antenna Switch Box CA010112
Power Adaptor CA017964
LOCATION DESCRIPTION PART NO.
Top COVER ASSEMBLY CA060278
Top Top Cover C060103
Top Keyboard Mask (64K) C060105
Top Indicator Strip C060106
Top Trim C060281
Top ~ Key caps C060562
Top Standoff (LED) C060944
Top Label/Nameplate C061071
Top. Keyboard Assy CA060046
Top Indicator PC Board Assy CA060568
Top Connector/Cable Assy CA060606
LED1-3 LED Pilot Lamp C014776
PCB/RFI SHIELD ASSEMBLY CA061074
Main Fasterner Latching (Heatsink) C014796
Main Fastener Latching C015344
Main Cartridge Guide C060097
Main Conn Retainer C060098
Main Upper CPU Shield C060285
Main Lower CPU Shield C060286
Main Conn, Edge, Rt Angle 15/30 C060410
Main Heatsink C060581
Main Stud, tri-mount C061488
Main Insulator Lower Shield C061123
Main Plastic Rivet C061490
Main PC Board Assy (MAIN) CA060588
Main Heat Sink Assy CA061135
Main RF Cable Assy (12 Ft) CA061177
1200XL Home Computer
Field Service Manual 5-1
