CASTER AND LEVELER ASSEMBLIES
BOTTOM VIEW
4008-01113-16
,,/---SCREW 8-32x1 PC-HWH
04-10633
SWIVEL MOUNTING BRACKET
LEVELER PLATE
4608-01219-11
20-10360
SCREW #8x1 l/16 PINHEAD
SWIVEL CASTER
1/2-13x3
CASTER SHAFT
WOOD SCREW
BOTTOM VIEW OF CABINET ASSEMBLY
4008-01113-16
-SCREW 8-32x1 PL-HWH
04-10633
SWIVEL MOUNTING BRACKET
4420-01128-00
l/4-20 KEPS
U
4608-01219-11
CREW #8x1 l/16 PINHEAD
LEG LEVELER
4424-01182-00
1/2-13x3
LEVELER NUT
1/2-13x3/4
GNC00006
7/a/99
BOTTOM VIEW OF SEAT ASEMBLY
3-5
