PRODUCT CONFIGURATION
Stand-Alone Units
Each game is ready to play right out of the shipping carton. Use the game menu system to set player
variables in advance, or you can accept the factory settings and leave the choices to the players.
Tandem Units
Linking allows players to compete against each other (on one course). Operator menus are the same as
in stand-alone games. Linking cables to connect games are factory installed. Use the crossover couplers
included in the spare parts to link two cabinets. Hardware is for attaching cabinets together is provided.
Cabinet Arrays
I Icn
=
Iqai
nntwnrk to connect more cabinets together. Network hubs can interconnect up to eight games.
VU”
u
8”
-, . .-...
-
Refer to the inside rear cover for more information about the optional Hub Linking Kit.
INSTALLATION
&
INSPECTION
A
I
WARNING: The cabinet is top-heavy. Use the handles when moving cabinets. Don’t
push against plastic parts. Don’t raise the marquee light box until instructed to do so.
0
Installation of the casters, leg levelers, and marquee bracket requires two individuals.
MARQUEE BRACKET
SPARE PARTS
MAIN CABINE
7/l
2/99
GAME UNPACKED AND READY FOR ASSEMBLY
