POWER SUPPLY COMPONENTS
FRONT VIEW
SWITCHING POWER SUPPLY
POWER SWITCH -+j
LINE FUSE--..
LINE VOLTAGE
OC POWER
CONNECTOR
k 7 AUXILIARY POWER
CONNECTOR
ADJUSTMENT
CONNECTOR
L INTERNAL
12VDC FAN
A.C. AUXILIARY POWER
D.C. MAIN POWER
HARD DISK DRIVE POWER
CONNECTOR
CONNECTOR
CONNECTOR
PINS FUNCTION COLOR
PINS FUNCTION COLOR
PINS FUNCTION COLOR
1 LINE BLACK
1,2,3 +5 VDC RED
1 +5 VDC RED
GROUND GREEN
4,5,6 RETURN BLACK 2.3
RETURN BLACK
NEUTRAL WHITE
7 -5 VDC BLUE
4 + 12 VDC YELLOW
8 +12 VDC YELLOW
9 -12 VDC WHITE
NOTE: Many computer grade power supplies use alternate wire colors.
This is acceptable as long as the pinout is CotTaCt.
POWER SUPPLY ASSEMBLY
(REouIRED FOR
EUROPEAN MODELS)
460801081-l 1
#8x11/16 H-F SCREW
4408-01128-00
#8-32 KEPS NUT
4700-ooo70-00
187x.625x.05
FLAT WASHER
POWER SUPPLY ASSEMBLY
WC00016
7/14/99
POWER SUPPLY BRACKEl
HOLDER CAP
5731-14529-00
FUSE 6.3A 250V
3-21
