[I
1.
Remove and set aside items from the shipping containers. Remove all packing material. Inspect
for damage. Check the main cabinet exterior, pedestal, shifter, and all of the seat surfaces.
[12-
Remove the keys from the steering wheel. Unlock and open the coin and cash doors. Electrical
cords, mechanical components, and game spare parts are packed inside the cash box.
TAMPER RESISTANT SCREW
7
FLAT WASHER
BRACKET
RAfSE
AND SECURE MARQUEE LIGHT BOX
A
I
WARNING: The marquee light box is not secure until the bracket has been installed.
Keep tools and fingers away from the top of the cabinet to prevent damage. Have the
0
second individual hold the box in place while completing the following steps.
Il3-
Slowly lift the rear of the marquee light box. Raise until the box rests upright on the main cabinet.
Remove the screws and lift the shipping panel off the cabinet.
[I
4.
Orient the marquee bracket over the top of the cabinet and the back of the light box. Align the
holes. Install tamper resistant screws. Tighten each screw with the wrench from the spare parts.
Remove the bracket and reinstall the panel if the light box must be lowered for cabinet relocation.
HASP
BRACKET
KEY LOCK
BRACKET
CABINET SHOWN
FOR REFERENCE
LOCK
PLATE
CARRIAGE
BOLT
CABINET SECURITY MODIFICATIONS
l-5
