CHECK CABINET AIR FLOW
L1
POWER SUPPLY
(EXHAUST AIR)
[
]
20. Check the cabinet to be certain that the cooling fan air paths are not blocked. The power supply
has rear vents. The game electronics fan is mounted at the lower left corner of the enclosure
directly behind the rear door air inlet. Keep manuals and other documents away from these areas.
1121.
Reinstall the rear door onto the cabinet. Lock the door and remove the key. Install the screws at
the sides of the door.
If
the cabinet requires extra security, install a padlock now (not supplied).
1-9
