4
Figure 1 : Adjustment of Saw Blade Rising Speed
The saw blade will not rise for safety reasons unless the top guard is fully closed.
2.2. TECHNICAL FEATURES
2.2 KW / 3 HP
D=450 mm (18”)
d=30-32 mm
3000 rpm
6-8 Bar
(90-120 psi)
14 lt/min
80x96x137 cm
(31”x38”x54”)
225 kg
(495 lbs)
Top Guard
Control Panel
Electric and Pneumatic
Panel
