6
PART NO PART NAME QTY
1 CR-450_ MOTOR_GROUP_BED 1
2 6205_ZZ_BEARING 2
3 CR-450_MOTOR_TENSION_LOG 1
4 CR-450_MOTOR_TENSION_SHEET_METAL 1
5 CR-450_BEARING_COVER 2
6 CR-450_SAW_SHAFT 1
7 CR-450_SAW_SHAFT_PIPE 1
8 PJ_BELT_MOTOR_PULLEY (Q52x56x10KNL) 1
9 PJ-483_BELT 1
10 MOTOR_2.2KW_B14_3000RPM 1
11 LME-30-UU 4
12 SAW COUPLING 1
13 WASHER 30-32 mm 1
14 SAW BLADE Ø450 (18”) 1
15 REAR CLEVIS SPECIAL WASHER 1
16 CR-450_SAW_FLANGE 1
17 CR-450_MOTOR_PULLEY_WASHER 1
18 CR-450_SAW_SHAFT_NUT 1
19 CR-450_MOTOR_TENSION_BOLT_PRESSING_WASHER 1
20 CR-450_SAW_SAFETY 1
21 A_H.B_M6x20 6
22 A_H.B_M8x20 1
