atecpool WBR-9.5H-A - User Manual

Questions and Answers

S
Steven MarquezAug 15, 2025
What to do if my atecpool Heat Pump works normally but the water is cooling down instead of heating up?
- B
  Bradley VanceAug 15, 2025
  If the water is cooling down instead of heating up, first verify the parameters and select the correct mode. If that's not the problem, check the voltage in the electrical wiring to the 4-way valve. If no electric potential is measured, replace the controller. If electric potential is measured, replace the coil. If the problem persists, have the heat pump checked by a refrigeration technician.
K
Kellie DeanAug 25, 2025
Why is there an abnormal amount of ice formed on the evaporator of my atecpool Heat Pump?
- A
  Anthony JohnsonAug 26, 2025
  An abnormal amount of ice on the evaporator may be due to insufficient air inflow, so check the location of the heat pump and remove any dirt that could be present on the evaporator. If the pool water is already quite hot (warmer than 29), the probability of ice formation increases, so lowering the set temperature is a possible option. Check the setting of the defrosting function together with your installer. Check the voltage in the electrical wiring to the 4-way valve. If electric potential is measured, replace the coil. If the problem persists, have the heat pump checked by a refrigeration technician. If there is not enough refrigerant, have the heat pump checked by a refrigeration technician.
L
Luis ScottNov 4, 2025
What to do if my atecpool WBR-9.5H-A Heat Pump works normally but there is no or insufficient heating?
- E
  Emma GriffinNov 5, 2025
  Several issues could be the cause. It could be due to insufficient capacity of the heat pump, in which case you should install a larger model or an extra heat pump and cover the pool to limit heat loss. If the compressor works but the fan doesn't, check the electrical wiring of the fan and replace the condenser or the fan motor if necessary. If the fan works but the compressor doesn't, check the electrical wiring of the compressor and replace the condenser or the compressor if necessary. Make sure there is sufficient air circulation. Check the temperature setting and set the correct temperature. Have the by-pass readjusted by the installer. Have the settings for automatic defrost control checked by the installer. If there is not enough refrigerant, have the heat pump checked by a refrigera...

Summary

Introduction

Performance Data and Specifications

Performance and Features

Highlights the efficiency, durability, and ease of use of the heat pump unit.

System Diagram Overview

Illustrates the internal working principle of the heat pump system.

Detailed Model Performance Data

Comprehensive technical specifications and performance metrics for various heat pump models.

Installation of the Heat Pump Unit

Installation Remarks

Important notes and general advice before commencing the installation process.

Monobloc Unit Dimensions

Physical dimensions for monobloc heat pump units in vertical series configurations.

Heat Pump Location Requirements

Guidelines for selecting an optimal installation site ensuring adequate airflow and accessibility.

Installation Cautions

Safety warnings and important considerations during the heat pump installation.

Pool Distance and Piping Considerations

Recommendations on the optimal distance from the pool and heat loss factors.

Check-Valve Installation Procedure

Instructions for installing a check-valve to protect the heat exchanger from chemicals.

Pool System Setup and By-Pass Connection

Guidance on setting up the pool system and connecting the essential by-pass assembly.

Electrical Hook-up and Wiring

Detailed instructions for safe and correct electrical connection and wiring of the unit.

First Time Start-up Procedure

Step-by-step guide for the initial startup and testing of the heat pump.

Condensation Explanation

Explanation of condensation formation and how to distinguish it from leaks.

Control the Heat Pump (LCD)

LCD Controller Functions and Overview

Explanation of the wire controller's buttons, display, and basic functions.

Changing Operational Modes (LCD)

How to switch between auto, cooling, and heating modes using the LCD controller.

Parameter Adjustment (LCD)

Guide on how to access and modify operational parameters via the LCD controller.

Parameter Settings and Definitions (LCD)

Table detailing parameters, ranges, defaults, and adjustment notes for LCD controllers.

Checking Current Status (LCD)

How to view real-time operational data like temperatures and status on the LCD.

Controller Lock and Unlock (LCD)

Instructions for locking and unlocking the LCD controller keypad to prevent accidental changes.

Control the Heat Pump (LED)

LED Controller Preparation and Illustration

Pre-startup checks and visual guide to the LED controller interface.

Starting and Changing Modes (LED)

Procedures for powering on the unit and selecting operational modes via the LED controller.

Checking and Setting Parameters (LED)

How to view and adjust operational parameters using the LED controller.

Advanced LED Controller Operations

Setting the clock, timers, and keypad lock functions on the LED controller.

Protection Systems

Water Flow and Pressure Protection

Safeguards against low water flow and high/low refrigerant pressure.

Temperature and Defrost Protections

Protections for compressor overheating, automatic defrost, and water temperature limits.

Anti-Frost Mechanisms

Systems designed to prevent freezing during cold weather conditions.

Direction

Swimming Pool Water Chemistry

Essential water chemistry parameters (pH, chlorine, TAC, salt) and their importance.

Heat Pump Winterizing Procedures

Steps for safely draining and protecting the unit during off-season storage.

Restarting the Pump After Winter

Instructions for safely reintroducing the heat pump into operation after winter.

Maintenance and Inspection

Routine Maintenance Tasks

Regular checks and cleaning procedures for optimal heat pump performance.

Troubleshooting Guide Overview

General guidance on diagnosing and resolving common heat pump operational problems.

Detailed Problem Resolution

Specific issues like no heating, water leaks, or ice formation with detailed solutions.

Failure Code Overview (LCD Controller)

Failure Code Overview (LED Controller)

Protect-300 Failure Code Overview (3 Phase Unit)

Wiring Diagram

General Wiring Diagram

Schematic illustrating the electrical connections for common heat pump models.

Model-Specific Wiring Schematics

Wiring diagrams tailored for specific heat pump model series and configurations.

Model-Specific Wiring Schematics

Wiring diagrams tailored for specific heat pump model series and configurations.

atecpool WBR-9.5H-A Specifications

General

Model	WBR-9.5H-A
Category	Heat Pump
Heating Capacity	9.5 kW
Cooling Capacity	8.0 kW
Refrigerant	R410A
Operating Temperature Range	-10°C to 45°C
Weight	85 kg
