Specifications
Function CS1798 CS17916
Computer
Connections
Direct 8 16
Max. 512 (via Cascade) 256 (via Cascade)
Port Selection OSD, Hotkey, Pushbutton
Connectors Console
Ports
KB 1 x USB Type A Female (Black)
Video 1 x HDMI Female
Mouse 1 x USB Type A Female (Black)
Speakers 2 x Mini Stereo Jack F (Green; 1 x front panel, 1 x rear panel)
KVM
Ports
KB /
Mouse
8 x USB Type B Female
(White)
16 x USB Type B Female
(White)
Video 8 x HDMI Female (White) 16 x HDMI Female (White)
Speakers 8 x Mini Stereo Jack Female
(Green)
16 x Mini Stereo Jack
Female (Green)
F/W Upgrade 1 x RJ11 Female (Black)
Power 1 x DC Jack
USB 2.0 Hub 2 x USB Type A Female (White)
(1 x front panel, 1 x rear panel)
Switches Port Selection 8 x Pushbutton 16 x Pushbutton
Reset 1 x Semi-recessed Pushbutton
F/W Upgrade 1 x Slide Switch
LEDs USB Link 8 (Green) 16 (Green)
On Line / Selected 8 (Orange) 16 (Orange)
Power 1 (Dark Green)
Emulation Keyboard / Mouse USB
Video 480i, 480p, 720p, 1080i, and 1080p (HDTV) / 1920 x 1200
@ 60Hz
Scan Interval 1–255 Seconds (Default: 5 secs)
Power Consumption DC 5.0V; 12.0W DC 5.0V; 12.2W
Environment Operating Temp. 0–50ºC
Storage Temp -20–60ºC
Humidity 0–80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 3.49 kg 3.86 kg
Dimensions
(L x W x H)
43.72 x 25.66 x 4.40 cm 43.72 x 25.66 x 4.40 cm

ATEN CS1798 Specifications

General

Device Type	KVM Switch
Ports	8
Video Resolution	1920 x 1200
Max Resolution	1920 x 1200
USB Ports	2
Audio Support	Yes
Number of local users supported	1
Number of remote users supported	0
Daisy Chain	No
HDCP Compatible	Yes
Switching Method	Hotkey
Dimensions	437.24 x 256.53 x 44 mm
Connectors	USB
