ATEN CS1942DP User Manual

CS1942DP / CS1944DP User Manual
14
Quad-Display (DCC Mode)
To expand your installation to a Quad-Display display, you can use DCC Mode
to connect two CS1942DP / CS1944DP units together, and use four displays in
unison.
To set up DCC mode, power off all devices, refer to the installation diagram on
the next page (the numbers in the diagram correspond to the steps, below), and
do the following:
1. Connect all the computers to the Host as described in Hardware Setup,
Cable Connections, page 11.
2. On the Client, using two DisplayPort cables, plug the DisplayPort
connectors into the DisplayPort sockets A and B in the same KVM port
section of the switch.
3. At the other end of the two DisplayPort cables, plug the monitor cable into
the respective ports on the computer.
4. Repeat steps 2 and 3 for all computers.
5. Plug the console monitors into the DisplayPort console ports located on
the Host’s and Client’s rear panel.
6. Use an RJ-45 cable to connect the DCC port of the Host to the DCC port
of the Client.
7. On the rear of the Client set the DCC switch to Secondary.*
8. On the rear of the Host set the DCC switch to Primary.
9. Power up the installation: plug in the power cord for the Host and Client,
then power on both. After both units are up, power on the computer/video
source devices.
Note: 1. P means Primary, and S means Secondary.
2. In DCC mode, the Client’s front panel pushbuttons are disabled,
and it takes all commands directly from the Host.
3. Setting the DCC switch to the S position will disable all front
panel pushbuttons on that switch.

ATEN CS1942DP Specifications

General

DC-in jack	Yes
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
Headphone outputs	4
DisplayPort version	1.2
DisplayPorts quantity	6
Number of computers controlled	2
Product color	Black
Rack mounting	No
Housing material	Metal
Scan interval	1, 5, 99 s
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Auto scan delay (max)	99 s
Auto scan delay (min)	1 s
Ethernet LAN (RJ-45) ports	1
Power source	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	Audio (3.5mm), DisplayPort to Mini DisplayPort, USB
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	335 mm
Width	156.6 mm
Height	44 mm
Weight	1540 g
