General| DC-in jack | Yes |
|---|---|
| Console ports | 3.5mm headphone, 3.5mm mic, DisplayPort, USB A |
| Headphone outputs | 4 |
| DisplayPort version | 1.2 |
| DisplayPorts quantity | 6 |
| Number of computers controlled | 2 |
| Product color | Black |
| Rack mounting | No |
| Housing material | Metal |
| Scan interval | 1, 5, 99 s |
| Video bandwidth | 60 Hz |
| Maximum resolution | 4096 x 2160 pixels |
| Auto scan delay (max) | 99 s |
| Auto scan delay (min) | 1 s |
| Ethernet LAN (RJ-45) ports | 1 |
| Power source | DC |
| Storage temperature (T-T) | -20 - 60 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 0 - 80 % |
| Cables included | Audio (3.5mm), DisplayPort to Mini DisplayPort, USB |
| Harmonized System (HS) code | 85176200 |
Weight and Dimensions| Depth | 335 mm |
|---|---|
| Width | 156.6 mm |
| Height | 44 mm |
| Weight | 1540 g |
