ATEN CS1942DP User Manual

CS1942DP / CS1944DP User Manual
viii
About this Manual
This User Manual is provided to help you get the most from your CS1942DP /
CS1944DP unit. It covers all aspects of installation, configuration and
operation. An overview of the information found in the manual is provided
below.
Chapter 1, Introduction, introduces you to the CS1942DP / CS1944DP. Its
purpose, features and benefits are presented, and its front, side, and back panel
components are described.
Chapter 2, Hardware Setup, describes how to set up your installation. The
necessary steps are provided.
Chapter 3, Basic Operation, explains the fundamental concepts involved
in operating the CS1942DP / CS1944DP.
Chapter 4, Hotkey Operation, details all of the concepts and procedures
involved in the Hotkey operation of your CS1942DP / CS1944DP installation.
Chapter 5, Keyboard Emulation, provides tables that list the PC to Mac
and PC to Sun keyboard emulation mappings.
Chapter 6, The Firmware Upgrade Utility, explains how to use the
CS1942DP / CS1944DP's firmware with the latest available versions.
An Appendix, which provides specifications and other technical information
regarding the CS1942DP / CS1944DP.

ATEN CS1942DP Specifications

General

DC-in jack	Yes
Console ports	3.5mm headphone, 3.5mm mic, DisplayPort, USB A
Headphone outputs	4
DisplayPort version	1.2
DisplayPorts quantity	6
Number of computers controlled	2
Product color	Black
Rack mounting	No
Housing material	Metal
Scan interval	1, 5, 99 s
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Auto scan delay (max)	99 s
Auto scan delay (min)	1 s
Ethernet LAN (RJ-45) ports	1
Power source	DC
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
Cables included	Audio (3.5mm), DisplayPort to Mini DisplayPort, USB
Harmonized System (HS) code	85176200

Weight and Dimensions

Depth	335 mm
Width	156.6 mm
Height	44 mm
Weight	1540 g
