InstallationManual
24
Descriptionoftheequipment
1.Characteristics
1.1 Vertical wall-mounted water heater (VM)
50litres 75litres
100
litres
100
litres
150
litres
Voltage(V)
230 V monophase
Resistor
Directhea-
tingelement
Directhea-
tingelement
Directhea-
tingelement
ceramic
Directhea-
tingelement
Power(W) 1200 1200 1200 1200 1650
Dimensions
(mm)
Ø 505 505 505 510 530
H 575 780 910 865 1165
A 370 570 750 750 1050
B / / / - 800
C 530 530 530 530 550
Heatingtime* 3h27 3h40 5h17 5h46 5h33
Qpr(Maintenance
consumption)**
0,82 1,05 1,25 1,33 1,48
V40(Quantityofhot
waterat40°C(litres))
143 189 192 279
Emptyweight(kg) 23 26 30 30 39
150
litres
200
litres
200
litres
150
litres
200
litres
Voltage(V)
230 V monophase TC (1)
Resistor ceramic
Directhea-
tingelement
ceramic
Directhea-
tingelement
Directhea-
tingelement
Power(W) 1800 2200 2200 1650 2200
Dimensions
(mm)
Ø 530 530 530 530 530
H 1165 1480 1480 1165 1480
A 1050 1050 1050 1050 1050
B 800 800 800 800 800
C 550 550 550 550 550
Heatingtime* 5h33 5h17 5h17 5h33 5h17
Qpr(Maintenance
consumption)**
1,48 1,73 1,73 1,48 1,73
V40(Quantityofhot
waterat40°C(litres))
279 382 382 279 382
Emptyweight(kg) 38 46 46 38 46
*Heatingtimeforheatingbetween15and65°C
**MaintenanceconsumptioninkWhfor24hoursforwaterat65°C(ambient20°C)
(1)Devicessuppliedreadyforusewiththreephase230/400V3~,possibletochangeonsitetosinglephase230V~
