Atlantic Compact 150 L - Maintenance; Description of the Water Heater

MaintenanceManual
3636
Descriptionofthewaterheater
Enamel tank
protection
Magnesium
anode
Inlet diffuser :
Cold water inlet
Protective
cover
direct heating
element, heating
element in direct
contact with
domestic hot water.
Sleeve for
temperature
sensor
Stainless steel
outlet pipe
Thermal
insulation
handle
( top and bottom )
Thewaterheateryouhavejustacquiredcomprises:
• atankcoveredwithaprotectivelayerofvitreousenamel;
• anenergycut-offdeviceincaseofanabnormaltemperaturerise;
• Athermostatensuringmaintenanceofthewatertemperature.
theheatingelementisanelectricresistancewhichheatsupthewatervolume.
For water heaters with direct heating element :
• thedirectheatingelementisdrownedinthewater.Toreplacethewaterheatershastobedrained.
For water heaters Steatite Magnesium :
• thesteatiteheatingelementisttedinansteelsleeve.Noneedtodrainthewaterheatertochangethehea-
tingelement.
