Atlantic Compact 150 L - Page 30

InstallationManual
2929
GB
Ceiling mounting kit for vertical wall-mounted model
D
• Usefulwhenthewallcannotsupporttheweightoftheappliance.
• Freesspaceunderthewaterheater.
• Robustastestedwithoverload(+50kg).
DistanceD=197mmminimumfor75to200l
DistanceD=225mmfor50l
strap kit
• Compulsoryforceilingxing.
• Canbeusedtousethexationsofanolddevice.
• Allowsyoutomovethedeviceafewcentimetersduringinstallation.
Spacer for 150 l to 300 l vertical model on pedestral
• Theidealsolutionwhenyouneedclearanceundertheunit.
• Facilitatestheimplementationofpiping.
220 mm
