18 2022 2096 26
Instruction book
Control piping and regulating system, duplex tank mount with dual control and solenoid valve
Reference
Description
1
Control panel
2
Pressure transducer
3
Pressure gauge
4
Air receiver
5
Vent
6
Pressure relief valve
7
Flow from interstage
8 Interstage dump valve (Used on CR-15
units only.)
9
Flow to compressor head unloaders
10
Discharge line
11
Compressor
12
3-way normally-open solenoid valve
