Atlas Copco CS 14 User Manual

13
Safety and operating
instructions
© 2010 Atlas Copco Craelius AB | 2010-06-28
03 Signs and stickers Ed.0
Service work
GDE00008 A
In the event of breakdown or during service work
the boom
falls diagonally,
which can
cause
injuries and damage to machinery.

During service work the boom must be secured in
place with straps or supports.
Stability
Max.
Max.
GDE00009 A
Electrical system
GDE00010 A
Be aware of high voltage, incorrect handling can
be fatal.

All work on th
e electrical syste
m must be car
ried out
by electricians accredited for the purpose.
Regulatory signs
General regulatory signs
GDE00011 A

Read the instructions.

Incorrect use of the machine can cause personal
injury and damage to machinery.

Observe the indications given by the warning signs
and follow given instructions in order to avoid
serious injuries.
GDE00012 A

Read the instructions.

The rig is equipped with a battery switch.
GDE00013 A

Read the instructions.

The carrier's battery supplies the hydraulic oil level
switch with current.

The battery switch must be turned on when drilling is
in progress.

Switch off the battery switch when rig is not in
operatio
n. If
this is not
done the battery will be
discharged.

Atlas Copco CS 14 Specifications

General

Brand	Atlas Copco
Model	CS 14
Category	Construction Equipment
Language	English
